After acquiring a fifth wheel for your travelling plans or business, what waits for you as the second step is the mechanical chore and installation. At this point, we can list several necessary pieces of equipment you would require when attaching or modifying your fifth wheel according to your towing vehicle. But the very first thing to note is that without a fifth-wheel hitch, your brand-new fifth wheel won't be able to do much of anything. These installations can be extremely labor-intensive endeavors. Is it more cost effective to have a professional install a 5th wheel hitch or to do it yourself? What takes place? In this article, we are going to cover the basics of the fifth wheel instalment and explore if it is the most practical way or not. If you have any further questions about the working mechanism of the fifth wheel, you may visit our blog to learn more in detail.
What is the fifth wheel, and how does it work with a hitch? Knowing what we are going to deal with is critical, for the foremost. A 5th wheel is an additional vehicle that is attached to a towing device through a hitch. It provides additional space primarily for carriage purposes. With the aid of a hitch that is installed in the bed of the truck, a fifth-wheel recreational vehicle can be attached to a tow vehicle. The design of hitch is comparable to that of a tractor trailer. The hitching principles are the same, despite the fact that this hitch is on a much more miniature scale.
Well, but how do we connect the truck bed to the hitch? A single jaw or a double jaw will be used to wrap around the kingpin of the trailer, depending on the hitch. It is extremely low-key and unruffled thanks to the fact that it is supported by the back axle of the vehicle that is conducting the pulling.
It is simple and quick to attach and detach a fifth-wheel trailer at any time. The ability to hitch and unhitch an RV is one of those skills that, with sufficient training and practice, virtually anyone can master. Despite this, a lot of people feel that it's easier to get things done when there's another person present to help.
There are three significant points we wanted to illuminate about having a fifth wheel before you begin with the installation: durability, pulling power capacity, and flexibility. These factors are critical to consider if you are going to use your towing vehicle for heavy-duty purposes or long way transportation as well as personal carriages. Therefore, each point gives you a different benefit once you install a fifth wheel.
A hitch that will withstand the test of time is something you should look into getting, and a 5th wheel hitch installation could be a smart option for you. Our 5th wheel hitches are incredibly sturdy because to the hitch rail system that we employ at Hitch King. This hitch rail kit is able to withstand, support, and strengthen the bed of your vehicle.
It is well knowledge that having a 5th wheel hitch enables you to carry a greater load. If you know you'll be carrying huge goods and a Reese hitch won't be enough, installing a fifth wheel hitch on your truck will allow it to tow more without placing additional strain on the truck itself.
Our fifth wheel hitches are designed to be quickly and easily removed when they are not being used for towing. This allows for secure storage or the creation of additional space in the truck bed. In addition, the fact that this function is detachable makes it simpler for you to upgrade in the future, should the need arise.
These quite practical factors are not the only ones, though, they provide essential benefits for all purposes. If you are convinced enough to use the fifth wheel in almost every duty, let us have a look at the installation process.
Many people do worry about the installation process, as it seems to require comprehensive knowledge and experience in truck mechanics. Well, this is valid to some extent when it comes to considering several details. However, it is always possible for you to undertake the whole process yourself successfully, -so long as you ensure that everything is safe. Besides, if you have a particular interest in these mechanical works, know that you are not alone! A lot of people who own fifth-wheel trailers prefer to install the hitch themselves. A fifth-wheel prep package comes with a lot of trucks that are made to tow.
Often, this package provides you with all the necessary piece of equipment you would require. There will be a puck-like mechanism that allows you to swiftly install a fifth-wheel hitch. However, if your truck did not come equipped with the appropriate features to add a fifth-wheel hitch, here is the good news -you can still install a hitch!
Putting a hitch on a truck that was not factory-prepared is more difficult compared to that of default hitched vehicles. For the installation process, a ratchet, socket set, crescent wrench, drill, drill bits, and torque wrench are required. Make sure you read the directions thoroughly, so you know precisely what you're doing and your hitch is installed properly.
This simple control mechanism is maybe the most critical step in the whole process. That is because it is extremely risky to tow your trailer with a hitch that has not been installed correctly if you want to avoid any kind of accident or unexpected detachments. With a loose attachment or poor-quality material, it is possible that your truck, trailer, as well as other vehicles on the road, could be damaged as a result.
If your vehicle already has a towing package, installing a 5th wheel hitch should not be too difficult of a task for you. Be sure to follow the directions provided for the hitch's assembly. After that, you can position the hitch inside the holes in the bed of your truck by first removing the covers that were previously covering them.
To make sure the hitch is tight, you need to rotate the levers and then insert the cotter pins such that the levers cannot be released. The assembly of the hitch will be part of this process that requires the most time.
Because fifth-wheel hitches are not standard equipment on all trucks, you will need to perform the installation on your own. To get started, take out the spare tire and position the front base rail of the hitch so that it is aligned with the front of the truck bed.
Due to the fact that this distance is different for long-bed and short-bed vehicles, it is essential to take correct measurements. Then, mark the drill sites for the front rail, and then drill a pilot hole. Check to see that the pilot hole is positioned in the appropriate spot, that the under-bed bracket is aligned with the hole that you just drilled, and that there are no issues with the subsequent holes that need to be drilled.
Now, you can drill the additional pilot holes for the front mount's remaining components. Make room for the bolts that come packaged with your fifth-wheel hitch rails by gradually enlarging the hole with the help of a step bit. After that, you may attach the under-bed bracket and secure the fifth-wheel rail by bolting them down.
The next step is to make sure that the height of your hitch is adjusted appropriately for your trailer. Place your trailer on a flat area, and using a measuring tape, take the distance from the ground to the bottom of the kingpin. Keep at least 5.5 inches of space between the rails of your truck bed and the trailer at all times. When traveling over uneven ground while pulling a trailer, this will assist prevent any potential collisions from occurring.
After that, you may start adjusting the position of the rear fifth-wheel rail and attach the legs of the hitch to the hitch itself. As you did with the front rail, mark the spots where you will drill, and then carefully enlarge the holes. After the hole has been enlarged to the appropriate size, you may then insert any additional bolts and bolt down the back base rail.
You will need to apply the appropriate amount of torque to each piece of hardware in accordance with the guidelines outlined in the fifth wheel hitch installation instructions. It is now possible to install the hitch system for the fifth-wheel into the rails. If all goes according to plan, you won't have to wait long before you're hitching a ride!
Always note that the fifth wheeler hitch is an important piece of equipment for your RV. It is imperative that the fifth-wheel hitch be installed correctly in order to maintain everyone's safety. You don't want to do anything that would hurt your car or get you into an accident. It is well worth the bare minimum expense to have our hitch professionally installed so that we can be sure it is done correctly. If you decide to do the project on your own, make sure you take the time to read and understand the directions.
Well, having gone through the steps for fifth wheel installation, now you have a broader view of the process to decide whether you can do it yourself or not. Bringing in a professional who installs fifth wheel hitches is something you should consider doing if you are unsure of your abilities or if you do not have the necessary equipment. When it comes to installing your hitch, they will probably have a great deal more experience and expertise than you do.
There is a wide range in price for the installation of a hitch, from $75 to $225, depending on the configuration of your car. To a large extent, it will be determined by the total number of holes that need to be drilled as part of your installation as well as the rate that the shop charges per hour for labor. Independent repair shops, as opposed to dealerships, will almost always provide you with better deals and perform superior work.
There are many RV stores that can assist you with attaching hitches to your RV. Because they frequently install fifth-wheel hitches on a wide variety of cars, they typically have a great deal of experience in this area. Yet, this does not necessarily make them the ideal option simply because they are experienced in the field.
Here are several advantages to consulting with or recruiting a professional to make a proper and safe installation.
An expert on the mechanics of fifth wheels is going to take the minutest detail into consideration when attaching a hitch to your vehicle. As you are not a professional, most probably, these details would not catch your attention, even though they might be crucial and pose possible risks if not considered. Therefore, experience matters, particularly when it comes to supply safety.
You may prefer installing your fifth wheel by yourself on the financial basis, and it may seem more affordable to do so. However, you may not be able to choose the best quality material or equipment and instead, opt for the cheapest one to reduce the cost. This would be a risky preference concerning the safety of your instalment. That is because a cheap material would easily and quickly wear out even in the least demanding conditions. This means that you would purchase the same product once more every time it breaks or wearies out. Besides, a professional knows which product is the best in terms of quality/performance. Therefore, do not hesitate to trust an expert if you want a perfect installation in every aspect.
Given these perspectives, a professional aids more effectively than your manual work in fifth wheel installment. As TULGA family, we are here to assist you in the whole process. For high-quality products and more information about fifth wheel hitches, you are welcome to TULGA Fifth Wheel Hitch with the best assistance and guide!
